CSS Property to Allow/Disallow Handwriting Input (i.e., "ink to text")

Authors: Rahul Arakeri, Adam Ettenberger, Ben Mathwig, Jenny Ma, Gastón Rodríguez

Status of this Document

This document is a starting point for engaging the community and standards bodies in developing collaborative solutions fit for standardization. As the solutions to problems described in this document progress along the standards-track, we will retain this document as an archive and use this section to keep the community up-to-date with the most current standards venue and content location of future work and discussions.

Introduction

Multiple platforms have implemented an API to support handwriting gestures on touch devices. In these platforms, the O.S. takes the gestures a user performed (via touch or stylus) and after applying some character recognition technology to the user's handwriting introduces text to the corresponding text editable input.

Web browsers that integrate this capability have to contend with other user agent defined touch behavior, for example, to determine if the gesture is intended to be a scroll or if it should be interpreted as handwriting. Whenever a user starts handwriting near a text editable input field the browser must first discern the user's intention, then change focus to the most appropriate editable input and then emit pointer events.

However, browsers that recognize handwriting behave differently from those that don’t, and handwriting input isn’t always desirable for every application.

Developers may need to disable handwriting input for a better user experience or specific app behaviors. Current methods to disable handwriting input cause friction for developers and are not standardized.

This feature introduces a new web standard that simplifies enabling or disabling handwriting input across multiple platforms. By specifying a new keyword in the touch-action CSS property, developers can now easily indicate whether an element or its subtree should allow handwriting input.

Goals

Give authors granular per-document and per-element control over which content should (dis)allow handwriting input.

Non-Goals

Use Cases

Some scenarios where a website or application may want to disable handwriting input:

example of handwriting input inserting the text "Hello World"

Proposed Solution

Introduce a new value, handwriting, to the CSS property touch-action which allows authors to specify whether an element should allow handwriting input.

The touch-action CSS property is used by authors to define for whether user agents should execute their direct manipulation behavior for touch and pen gestures. When the spec was written this only included panning and zooming, which were addressed jointly via the manipulation keyword. This change would modify the meaning of the manipulation value for touch-action to also indicate that the user agent may consider handwriting interactions on the element.

When the touch-action CSS property is specified for an element, only the mentioned behaviors will be enabled on the element and all the possible touch-action values that are not explicitly mentioned are then disabled for the element.

Authors are used to the recommended practice of adding touch-action: none to elements over which they wish to handle all events themselves.

Syntax

<style>
.handwritable {
  touch-action: handwriting;
}
.not-handwritable {
  touch-action: pan-x;
}
</style>

<textarea class="handwritable"></textarea>                    <!-- the computed handwriting value is true -->
<textarea class="not-handwritable"></textarea>                <!-- the computed handwriting value is false -->
<textarea></textarea>                                         <!-- the computed handwriting value is true -->
<textarea style="touch-action:handwriting;"></textarea>       <!-- the computed handwriting value is true -->
<textarea style="touch-action:pan-x;"></textarea>             <!-- the computed handwriting value is false -->
<textarea style="touch-action:pan-x handwriting;"></textarea> <!-- the computed handwriting value is true -->
<textarea style="touch-action:manipulation;"></textarea>      <!-- the computed handwriting value is true -->

<!-- Having a parent that disables handwriting causes all its children to lose handwriting capabilities -->
<div style="touch-action:pan-x;">                             <!-- the computed handwriting value is false -->
  <textarea></textarea>                                       <!-- the computed handwriting value is false -->
  <textarea style="touch-action:handwriting;"></textarea>     <!-- the computed handwriting value is false -->
</div>

<div class="handwritable">
  <textarea></textarea>                                       <!-- the computed handwriting value is true -->
  <textarea class="not-handwritable"></textarea>              <!-- the computed handwriting value is false -->
</div>

Keywords and States

The touch-action attribute currently accepts the following keywords:

Value: auto | none | [ [ pan-x | pan-left | pan-right ] | [ pan-y | pan-up | pan-down ] ] | pinch-zoom | manipulation

The handwriting keyword indicates whether an element and the element's descendants will allow handwriting input when supported by the user agent. Handwriting will only be allowed for an element when its computed touch-action includes the handwriting keyword. By default, auto and manipulation will include the handwriting keyword.

Keyword interactions

Distinction between gesture intentions is left to the User Agent, and determining whether a user intends to pan, zoom or write is beyond the scope of this keyword which only determines if the gesture is available. In scenarios where both handwriting and pan-* are enabled (such as auto or manipulation, etc.) the User Agent will be responsible for determining which action takes place.

User Agents may implement certain capabilities to be exclusive to certain devices, like handwriting only being available for styluses. At the moment, the touch-action property does not allow for a granular enablement of gesture by discriminating between pointer devices. It will be the responsibility of User Agents to handle these complexities when implementing the handwriting keyword.

Determining enablement

All CSS properties have computed values for all elements. The enablement of handwriting in a given element can be determined by running the following steps:

  1. If the computed value for touch-action on element and all of its ancestors include either keyword auto, handwriting, or manipulation, enable handwriting.
  2. If the computed value for touch-action on element or any of its ancestors does not include either keyword auto, handwriting, or manipulation, disable handwriting.

Caveats / Cons

A few pain points have been brought up that are worth discussion:

Privacy and Security Considerations

Privacy

Since the proposed property should not interact with other HTML or IDL attributes, DOM properties, or JavaScript APIs in an interesting way, and the property doesn't reflect whether a user agent supports or has enabled handwriting input, it shouldn't be possible to use this for fingerprinting. As of writing this, we are not aware of any way the proposed property could be used towards nefarious means since it's merely a hint for the browser to allow handwriting input and the handwriting state doesn't expose anything about the user nor their device.

Security

There are no known security impacts of the features in this specification.

Alternative Solutions

The proposal is for this to be an CSS property.

Why not an HTML+IDL attribute?

The first proposal was to add the handwriting functionality as an HTML+IDL attribute which would allow authors to specify whether an element should permit handwriting by adding a new handwriting(= true|= false|<blank>) (<blank> implying = true) attribute to HTML elements. The main arguments to implement the handwriting HTML attribute over a css property are:

After some discussion [1] [2], it became apparent that implementing the functionality in the touch-action CSS attribute was the better alternative. The main arguments in favor of touch-action were:

[...] For use cases where the author wants to handle the pointerevents themselves (e.g. in order to accept free-form drawing) they should be using touchaction or preventDefault on the events to tell the browser they are handling them. They shouldn't have to recognize that if there happens to be an input field underneath or nearby that they need to disable handwriting on it. The developer authoring the drawing widget may not be aware that it may be on top of or near an input element, and it seems bad if they need to find such elements and disable handwriting on them."

Why not an HTML+IDL attribute that interacts with touch-action?

touch-action:none; is the accepted and recommended way of disabling all types of touch interaction with the elements. The HTML attribute would not be able to override the touch-action property in these scenarios. By accepting touch-action as a filter, developers would lose the flexibility of disabling scrolling while enabling handwriting. Consider the following scenarios:

The last entry that fails is equivalent of touch-action: handwriting. In order to implement this handwriting control mechanism, the touch-action:none; recommendation would have to be modified.

Why not a JavaScript API?

(e.g., e.enableHandwriting() or e.setHandwritingState(...), e.getHandwritingState() and e.getComputedHandwritingValue())

Why not some combination of all the above?

Why not extend a different attribute or property?

[HTML] inputmode:

[CSS] pointer-events:

References and acknowledgements

Stakeholder Feedback / Opposition

Summary of the feedback on the current proposal:

References
